হিসাব করে দেখুন: আইপিএস ও ব্যাটারি ক্যালকুলেটর দিয়ে আপনার কত ভিএ-র আইপিএস আর কত Ah ব্যাটারি লাগবে দেখে নিন।
বিদ্যুৎ গেলে স্মার্ট হোমের কী হয়
বেশিরভাগ স্মার্ট প্লাগ, বাল্ব আর সুইচ ওয়াই-ফাইয়ের মাধ্যমে চলে। বিদ্যুৎ গেলে একসঙ্গে দুটি জিনিস বন্ধ হয়: ডিভাইসটি নিজে, আর আপনার রাউটার ও ইন্টারনেট সংযোগ। বাসায় আইপিএস থাকলে লাইট-ফ্যান চলতে থাকে, কিন্তু রাউটার আইপিএস লাইনে না থাকলে ফোনের অ্যাপ থেকে কিছুই নিয়ন্ত্রণ করা যায় না।
প্রথম কাজ: রাউটার আর ওএনইউ চালু রাখুন
- ফাইবার ইন্টারনেটে দুটি যন্ত্র থাকে: ওএনইউ (যেখানে ফাইবার তার ঢোকে) আর ওয়াই-ফাই রাউটার। দুটোকেই ব্যাকআপে রাখতে হবে; একটি বন্ধ হলেই ইন্টারনেট চলে যায়।
- এ কাজের সবচেয়ে সহজ সমাধান একটি মিনি ডিসি ইউপিএস, যা রাউটার ইউপিএস নামে বিক্রি হয়। কেনার আগে রাউটার ও ওএনইউ-এর অ্যাডাপ্টারে লেখা ভোল্টেজ (সাধারণত ৯ বা ১২ ভোল্ট) মিলিয়ে নিন, আর দেখুন ইউপিএসটি অন্তত ততটা অ্যাম্পিয়ার দিতে পারে কি না (দুটি যন্ত্র একই ইউপিএসে চললে দুটির যোগফল)।
- বাসায় আইপিএস থাকলে রাউটারের সকেটটি আইপিএস লাইনে আছে কি না ইলেকট্রিশিয়ানকে দিয়ে যাচাই করিয়ে নিন। মনে রাখবেন, আপনার এলাকায় ইন্টারনেট সেবাদাতার যন্ত্রপাতিতে বিদ্যুৎ না থাকলে নিজের ব্যাকআপ থাকা সত্ত্বেও ইন্টারনেট চলে যেতে পারে।
মিনি ইউপিএস কেনার আগে ৫টি বিষয় মিলিয়ে নিন
রাউটার, ওএনইউ আর মিনি ইউপিএসের লেবেল বা নির্মাতার স্পেসিফিকেশন পাশাপাশি রেখে মিলিয়ে নিন। মডেলভেদে এগুলো আলাদা হয়, তাই অন্যের অভিজ্ঞতা বা বিজ্ঞাপনের ওপর ভরসা না করে আপনার নির্দিষ্ট মডেলের তথ্য দেখুন।
- ভোল্টেজ: প্রতিটি ডিভাইসের অ্যাডাপ্টারে লেখা আউটপুট ভোল্টেজ (যেমন 9V বা 12V) দেখুন। ইউপিএসের যে পোর্টে লাগাবেন, তার ভোল্টেজ হুবহু এক হতে হবে। ভুল ভোল্টেজে ডিভাইস নষ্ট হতে পারে।
- কানেক্টর: পিনের মাপ (যেমন 5.5 × 2.1 মিমি) মিলতে হবে। জোর করে ঢোকাবেন না; মাপ না মিললে নির্মাতার অনুমোদিত ক্যাবল বা কানেক্টর ব্যবহার করুন।
- পোলারিটি: অ্যাডাপ্টারের গায়ের চিহ্ন দেখে নিন, ভেতরের পিন প্লাস (+) নাকি মাইনাস (−)। ইউপিএসের পোর্টের পোলারিটিও একই হতে হবে।
- কারেন্ট: ইউপিএসের পোর্ট যত অ্যাম্পিয়ার দিতে পারে, তা ডিভাইসের অ্যাডাপ্টারে লেখা অ্যাম্পিয়ারের সমান বা বেশি হলে নিশ্চিন্ত থাকতে পারেন।
- মোট ক্ষমতা: সব পোর্ট মিলিয়ে ইউপিএস সর্বোচ্চ কত ওয়াট দিতে পারে, স্পেসিফিকেশনে দেখুন। একসঙ্গে যেসব ডিভাইস চালাবেন, সেগুলোর আসল মোট টান এই সীমার মধ্যে থাকতে হবে। অ্যাডাপ্টারের লেবেল সেই অ্যাডাপ্টারের সর্বোচ্চ সীমা বোঝায়, ডিভাইস আসলে কত ওয়াট টানে তা নয়; তাই লেবেলগুলোর যোগফল বেশি দেখালেই ইউপিএস ওভারলোড হবে, এমন নয়। সন্দেহ থাকলে বিক্রেতা বা নির্মাতার কাছে লিখিতভাবে জেনে নিন।
কত ঘণ্টা চলবে: আনুমানিক হিসাব
ব্যাকআপের সময় নির্ভর করে তিনটি জিনিসের ওপর: ব্যাটারিতে কত শক্তি (Wh), ডিভাইসগুলো আসলে কত ওয়াট টানে, আর ব্যাটারি থেকে ৯ বা ১২ ভোল্টে রূপান্তরে কতটা শক্তি নষ্ট হয়।
আনুমানিক সময় (ঘণ্টা) = ব্যাটারির Wh × রূপান্তর দক্ষতা ÷ ডিভাইসগুলোর মোট টান (ওয়াট)
- লেবেলে Wh লেখা থাকলে সেটাই নিন। শুধু mAh লেখা থাকলে সেই mAh কোন ভোল্টেজে, সেটাও লাগবে (Wh = mAh × ভোল্ট ÷ ১০০০)। ভোল্টেজ লেখা না থাকলে বিক্রেতার কাছে Wh জেনে নিন।
- ডিভাইসগুলো আসলে কত ওয়াট টানে, তা জানতে প্লাগ-ইন পাওয়ার মিটার লাগে। মাপা না থাকলে যে সংখ্যা ধরবেন, সেটা অনুমান হিসেবেই ধরুন।
- রূপান্তর দক্ষতা নির্মাতা না জানালে সেটাও অনুমান। নিচের উদাহরণে ৮০% ধরা হয়েছে।
উদাহরণ (শুধু হিসাব বোঝাতে; কোনো মডেল বা মাপা তথ্য নয়): লেবেলে ৩০ Wh আর দক্ষতা ৮০% ধরলে ব্যবহারযোগ্য শক্তি প্রায় ২৪ Wh। রাউটার আর ওএনইউ মিলে ৬ ওয়াট টানলে প্রায় ৪ ঘণ্টা, ৮ ওয়াটে প্রায় ৩ ঘণ্টা, ১২ ওয়াটে প্রায় ২ ঘণ্টা।
পুরোনো ব্যাটারি, গরম ঘর বা বেশি ব্যবহারে সময় আরও কমতে পারে। আপনার এলাকায় একটানা যতক্ষণ বিদ্যুৎ থাকে না, তার চেয়ে কিছুটা বেশি সময়ের হিসাবে ইউপিএস বাছুন। আর মনে রাখবেন, আপনার আইএসপি (ISP)-র লাইনে বিদ্যুৎ না থাকলে শুধু বাসার ব্যাকআপে ইন্টারনেট চলবে না।
নিরাপত্তা: মিনি ইউপিএস বা অ্যাডাপ্টারের বডি (কেসিং) খুলবেন না। রাউটারের সকেট আইপিএস লাইনে আনতে চাইলে মেইন সুইচ বন্ধ করে দক্ষ ইলেকট্রিশিয়ানকে দিয়ে করান।
কোন ডিভাইস ইন্টারনেট ছাড়াও চলে
কিছু ডিভাইস টাইমার বা শিডিউল নিজের ভেতরে জমা রাখে, তাই ইন্টারনেট না থাকলেও সময়মতো চালু-বন্ধ হয়। অন্যগুলো প্রতিটি কাজের জন্য ক্লাউডের ওপর নির্ভর করে। কেনার সময় পণ্যের বিবরণে “local timer”, “offline schedule” বা “LAN control” লেখা আছে কি না দেখুন, আর বিক্রেতাকে সরাসরি জিজ্ঞেস করুন।
বিদ্যুৎ ফিরলে ডিভাইস কী করবে
বিদ্যুৎ ফিরলে স্মার্ট প্লাগ বা সুইচ কোন অবস্থায় থাকবে, সেটি অ্যাপের একটি সেটিং, সাধারণত “Power-on behaviour” বা “Relay status” নামে। এটি “আগের অবস্থা” বা “বন্ধ” হিসেবে সেট করে রাখুন। নইলে মাঝরাতে বিদ্যুৎ এলে সব লাইট একসঙ্গে জ্বলে উঠতে পারে। ইস্ত্রি, হিটার বা গরম হয় এমন যেকোনো যন্ত্রের জন্য সবসময় বন্ধ (Off) বেছে নিন: আগের অবস্থা বেছে রাখলে বিদ্যুৎ যাওয়ার সময় চালু থাকা যন্ত্রটি বিদ্যুৎ ফিরলেই নিজে থেকে আবার চালু হয়ে যাবে, খালি বাসায়ও।
আইপিএসের ক্ষমতার হিসাব
স্মার্ট প্লাগ বা সুইচ নিজে খুব কম বিদ্যুৎ নেয়। আসল হিসাব হলো প্লাগে কী লাগাচ্ছেন। ফ্রিজ, পানির মোটর বা এসি সাধারণ বাসার আইপিএসে চালানোর পরিকল্পনা করবেন না। আইপিএস লাইনে লাইট, ফ্যান, রাউটার আর ছোট যন্ত্রই রাখুন।
এক নজরে
- রাউটার ও ওএনইউ ব্যাকআপে রাখুন।
- অফলাইন টাইমার আছে এমন ডিভাইস বেছে নিন।
- প্রতিটি প্লাগ ও সুইচের পাওয়ার-অন সেটিং ঠিক করুন।
- আইপিএসে শুধু হালকা লোড রাখুন।
Work it out: use the IPS and battery calculator to see what IPS size and battery you need.
What happens to a smart home in a power cut
Most smart plugs, bulbs and switches work over Wi-Fi. When the power goes, two things stop at once: the device itself, and your router and internet connection. If you have an IPS, your lights and fans keep running, but unless the router is also on the IPS line, the phone app can no longer control anything.
First job: keep the router and ONU alive
- Fibre internet uses two boxes: the ONU (where the fibre cable comes in) and the Wi-Fi router. Both need backup; if either one is off, there is no internet.
- The simplest fix is a mini DC UPS, often sold as a router UPS. Before buying, match the voltage printed on your router and ONU adapters (usually 9 V or 12 V) and check that the UPS can supply at least the current they are rated for (combined, if both run from one UPS).
- If you have an IPS, ask your electrician to confirm the router’s socket is on the IPS line. If your internet provider’s local equipment loses power, the internet can still drop even with your own backup.
Five checks before you buy a mini UPS
Put the labels or the maker’s specifications for your router, ONU and mini UPS side by side. These differ from model to model, so go by your exact model’s details rather than someone else’s experience or an advert.
- Voltage: read the output voltage on each device’s adapter (for example 9V or 12V). The UPS port you use must give exactly the same voltage. The wrong voltage can damage the device.
- Connector: the plug size (for example 5.5 × 2.1 mm) must match. Don’t force it; if it doesn’t fit, use a cable or connector the maker approves.
- Polarity: check the symbol on the adapter to see whether the centre pin is positive (+) or negative (−). The UPS port must have the same polarity.
- Current: you’re on the safe side when the UPS port can supply at least the amps printed on the device’s adapter.
- Total output: check the maximum total watts the UPS can supply across all ports. The real combined draw of everything you connect must stay within it. An adapter label shows that adapter’s maximum, not what the device actually uses, so a high total of label ratings doesn’t by itself mean the UPS will overload. If in doubt, ask the seller or maker in writing.
How long it lasts is an estimate
Backup time depends on three things: how much energy the battery holds (Wh), how many watts your devices actually draw, and how much energy is lost converting the battery’s output to 9V or 12V.
Estimated hours = battery Wh × conversion efficiency ÷ total draw of your devices (W)
- If the label gives Wh, use that. If it only gives mAh, you also need the voltage that mAh figure refers to (Wh = mAh × volts ÷ 1,000). If no voltage is given, ask the seller for the Wh.
- Knowing what your devices really draw takes a plug-in power meter. Without a measurement, treat any figure you use as an assumption.
- Unless the maker states the conversion efficiency, that is an assumption too. The example below assumes 80%.
Example (to show the sum only; not a real model or a measurement): 30 Wh on the label at an assumed 80% efficiency leaves about 24 Wh to use. If the router and ONU together draw 6 W, that’s about 4 hours; at 8 W, about 3 hours; at 12 W, about 2 hours.
An older battery, a hot room or heavy use can shorten this further. Choose a UPS for somewhat longer than your usual longest power cut. And remember: if your internet provider’s equipment loses power, backup at home won’t bring the internet back.
Safety: don’t open a mini UPS or an adapter. If you want the router’s socket moved onto the IPS line, have a qualified electrician do it with the main switch off.
Which devices work without the internet
Some devices store their timers and schedules on the device itself, so they keep switching on time with no internet. Others depend on the cloud for everything. When buying, look for “local timer”, “offline schedule” or “LAN control” in the product description, and ask the seller directly.
What the device does when power returns
What a smart plug or switch does when the power comes back is a setting in its app, usually called “Power-on behaviour” or “Relay status”. Set it to “Previous state” or “Off”. Otherwise every light can come on at once when power returns at 3 a.m. For an iron, heater or anything else that heats up, always choose Off: with Previous state, an appliance that was on when the power went will switch itself back on when power returns, even in an empty flat.
Sizing the IPS
A smart plug or switch uses very little power itself. What matters is what you plug into it. Don’t plan to run a fridge, water pump or air conditioner on a typical home IPS. Keep the IPS line for lights, fans, the router and small devices.
Checklist
- Put the router and ONU on backup.
- Choose devices with offline timers.
- Set the power-on behaviour of every plug and switch.
- Keep only light loads on the IPS.
